Description
The Kordz ONE 16AWG 2 Core OFC Speaker Cable 305m Yellow LSZH is engineered to make professional speaker cable installations faster, cleaner and more reliable. Combining high-purity 99.99% Oxygen Free Copper conductors with an easy-glide Low Smoke Zero Halogen jacket, it delivers dependable audio performance while simplifying cable routing and handling on site.
Designed specifically for AV integrators, electricians and installation professionals, the cable uses medium-stranded OFC conductors to provide an excellent balance of flexibility and power handling. The polished copper surface helps minimise oxidation, supporting long-term performance and signal integrity across residential and commercial audio systems.
Kordz’s Reel-in-Box packaging allows the cable to dispense smoothly during installation, helping reduce twists, tangles and cable waste. Combined with metre markings and a high-visibility yellow jacket for easy identification, it is an ideal solution for multi-room audio, education, distributed audio, home cinema and commercial sound installations.
Features
- 16AWG 2 Core Speaker Cable
- 305m professional installation reel
- 99.99% Oxygen Free Copper (OFC) conductors
- Medium-stranded conductors for flexibility and power handling
- Polished conductor surface to minimise oxidation
- LSZH (Low Smoke Zero Halogen) construction
- Easy-glide jacket for easier cable pulling and routing
- Industry-standard red and black conductor identification
- High-visibility yellow outer jacket
- Reel-in-Box packaging reduces tangles and installation time
- Metre-marked cable for easier installation planning
- Suitable for distributed audio, multi-room audio and commercial AV systems
- AS/NZS S008:2010 compliant
- RoHS compliant
Specifications
- Part Number: K11402-305M-YL
- Series: Kordz ONE
- Cable Type: Speaker Cable
- Conductor Size: 16AWG
- Number of Cores: 2
- Cable Length: 305m
- Colour: Yellow
- Conductor Material: 99.99% Oxygen Free Copper (OFC)
- Number of Strands: 65
- Conductor Area: 1.309mm²
- Strand Diameter: 0.16 ± 0.008mm
- Core Insulation Material: LSZH
- Core Insulation Diameter: 2.30 ± 0.10mm
- Core Insulation Thickness: 0.40mm
- Filler Material: Nylon
- Outer Jacket Material: LSZH
- Overall Cable Diameter: 6.00 ± 0.20mm
- Jacket Thickness: 0.60mm
- Minimum Bend Radius: 22.8mm
- Operating Temperature: -20°C to 60°C
- Installation Temperature: 0°C to 50°C
- Insulation Resistance: Minimum 100MΩ
- Conductor Resistance: Maximum 13.7Ω/km at 20°C
- Dielectric Strength: 500V AC for 1 Minute
- Compliance: AS/NZS S008:2010, RoHS, REACH & HF
- Fire Rating: CPR Eca
- Packaging Style: Reel-in-Box
- Packaging Dimensions: 330mm × 265mm × 340mm
